Optimize your solar energy system with the ml-series 40a mppt solar charge controller
key features:
Low self-consumed power:
designed with energy efficiency in mind, the self-consumed power of the controller is minimized, ranging from 0.7w to 1.2w. This ensures minimal impact on your system, optimizing energy utilization.
Wide battery compatibility and customization:
compatible with various battery types, this controller allows customization of battery charging parameters, providing flexibility to adapt to different energy storage solutions. It supports both 12v and 24v system voltages.
Comprehensive protection and monitoring:
the controller comes with a temperature sensor for monitoring battery temperature, enhancing battery life and ensuring safety. The unit is equipped with protective features, including reverse polarity, overcharging, over-discharging, overload, and short-circuit protection.
Remote monitoring via bluetooth:
for convenient monitoring and control, an optional Bluetooth module can be added. This feature enables you to check historic data and make adjustments using a user-friendly app on your smartphone.
Specifications:
- system voltage: 12/24v
- maximum solar open circuit voltage (v. O. C): 100vdc
- maximum solar voltage (v. M. P): 75vdc
- dc-dc conversion frequency: 40khz
- solar input power:
- 12v battery bank: 550 watts
- 24v battery bank: 1100 watts
- rated charge current: 40amps
- rated load current: 20amps
- self-consumed power: <10ma
- operating temperature: -35c to +45c
- protection degree: ip32
- communication method: rs232
- dimensions: 238mm x 173mm x 72mm
- weight: 2kgs
package contents:
- 1 x mppt solar charge controller 40a
